Model Number
 LH-NP12TB-B

Pixel Configuration
• Flip Chip COB (Chip-on-Board)

Pixel Pitch
• LH-NP09TB-B: 0.94 mm
• LH-NP12TB-B: 1.25 mm

Module Resolution
• LH-NP09TB-B: 160 × 180 Pixels
• LH-NP12TB-B: 120 × 135 Pixels

Module Dimensions
• 150 × 168.75 mm

Module Weight
• 0.17 kg

Modules per Cabinet
• 4 × 2 Modules

Cabinet Resolution
• LH-NP09TB-B: 640 × 360 Pixels
• LH-NP12TB-B: 480 × 270 Pixels

Cabinet Dimensions (W × H × D)
• LH-NP09TB-B: 600 × 337.5 × 38.8 mm
• LH-NP12TB-B: 600 × 337.5 × 43.5 mm

Cabinet Surface Area
• 0.2025 m²

Weight per Square Meter
• 20 kg/m²

Pixel Density
• LH-NP09TB-B: 1,137,777 Pixels/m²
• LH-NP12TB-B: 640,000 Pixels/m²

Cabinet Flatness
• ±0.05 mm

Cabinet Material
• Die-Cast Aluminum

Service Access
• Front Maintenance

Brightness
• 600 Nits (Typical)
• 1200 Nits (Peak)

Color Temperature
• Adjustable from 3200K to 9300K

Viewing Angle
• Horizontal: 170°
• Vertical: 170°

Brightness Uniformity
• 98.2%

Color Uniformity
• ±0.002 Cx, Cy

Contrast Ratio
• 15,000:1

Processing Depth
• 14-bit (Up to 20-bit Internal Processing)

Power Consumption
• Maximum: 60W per Cabinet (296W/m²)
• Average: 20W per Cabinet

Heat Dissipation
• Maximum: 205 BTU/h per Cabinet
• Maximum: 1012 BTU/h per m²

Power Supply
• AC 100–240V

Frame Rate
• 50 / 60 Hz

Refresh Rate
• 3840 Hz

LED Lifetime
• Up to 100,000 Hours (50% Brightness)

Operating Temperature
• -10°C to +45°C

Operating Humidity
• 10%–90% RH

IP Rating
• Front: IP50
• Rear: IP20
