Model Series
• LH-NP09P27 / LH-NP12P27 / LH-NP15P27 / LH-NP18P27 / LH-NP25P27

Pixel Configuration
• SMD 3-in-1 LED

Pixel Pitch
• LH-NP09P27: 0.94 mm
• LH-NP12P27: 1.25 mm
• LH-NP15P27: 1.56 mm
• LH-NP18P27: 1.88 mm
• LH-NP25P27: 2.50 mm

Module Resolution
• LH-NP09P27: 320 × 180 Pixels
• LH-NP12P27: 240 × 135 Pixels
• LH-NP15P27: 192 × 108 Pixels
• LH-NP18P27: 160 × 90 Pixels
• LH-NP25P27: 120 × 68 Pixels

Module Dimensions
• 300 × 168.75 mm

Module Weight
• 0.49 kg

Modules per Cabinet
• 4 Modules

Cabinet Resolution
• LH-NP09P27: 640 × 360 Pixels
• LH-NP12P27: 480 × 270 Pixels
• LH-NP15P27: 384 × 216 Pixels
• LH-NP18P27: 320 × 180 Pixels
• LH-NP25P27: 240 × 135 Pixels

Cabinet Dimensions (W × H × D)
• 600 × 337.5 × 57 mm

Cabinet Surface Area
• 0.203 m²

Cabinet Weight
• 6.2 kg

Weight per Square Meter
• 31 kg/m²

Pixel Density
• LH-NP09P27: 1,137,777 Pixels/m²
• LH-NP12P27: 640,000 Pixels/m²
• LH-NP15P27: 409,600 Pixels/m²
• LH-NP18P27: 284,444 Pixels/m²
• LH-NP25P27: 160,000 Pixels/m²

Cabinet Flatness
• ±0.1 mm

Cabinet Material
• Die-Cast Aluminum

Service Access
• Front & Rear Maintenance

Brightness
• 800 Nits (After Calibration)

Color Temperature
• Adjustable from 3000K to 10000K

Viewing Angle
• Horizontal: 160°
• Vertical: 160°

Brightness Uniformity
• 98.2%

Color Uniformity
• ±0.003 Cx, Cy

Contrast Ratio
• 7000:1

Processing Depth
• 16-bit

Power Consumption (Maximum)
• LH-NP09P27: 108W per Cabinet (540W/m²)
• LH-NP12P27: 106W per Cabinet (530W/m²)
• LH-NP15P27: 106W per Cabinet (530W/m²)
• LH-NP18P27: 100W per Cabinet (500W/m²)
• LH-NP25P27: 92W per Cabinet (460W/m²)

Power Consumption (Average)
• 36W per Cabinet

Heat Dissipation
• LH-NP09P27: 368 BTU/h Max, 373 BTU/h Avg, 1842 BTU/h/m²
• LH-NP12P27: 362 BTU/h Max, 366 BTU/h Avg, 1808 BTU/h/m²
• LH-NP15P27: 362 BTU/h Max, 366 BTU/h Avg, 1808 BTU/h/m²
• LH-NP18P27: 341 BTU/h Max, 345 BTU/h Avg, 1706 BTU/h/m²
• LH-NP25P27: 314 BTU/h Max, 318 BTU/h Avg, 1570 BTU/h/m²

Power Supply
• AC 100–240V

Frame Rate
• 50 / 60 Hz

Refresh Rate
• 3840 Hz

LED Lifetime
• Up to 100,000 Hours (50% Brightness)

Operating Temperature
• -10°C to +40°C

Operating Humidity
• 10%–80% RH

IP Rating
• Front: IP51
• Rear: IP50

Application
• Indoor LED Display System
