Model Series
• LH-NP09M9 / LH-NP09M7 / LH-NP09M4
• LH-NP10M9 / LH-NP10M7 / LH-NP10M4
• LH-NP12M9 / LH-NP12M7 / LH-NP12M4
• LH-NP14M9 / LH-NP14M7 / LH-NP14M4
• LH-NP15M9 / LH-NP15M7 / LH-NP15M4
• LH-NP18M9 / LH-NP18M7 / LH-NP18M4
• LH-NP20M9 / LH-NP20M7 / LH-NP20M4
• LH-NP25M9 / LH-NP25M7 / LH-NP25M4
• LH-NP30M9 / LH-NP30M7 / LH-NP30M4

Pixel Configuration
• SMD LED Technology

Pixel Pitch
• 0.968 mm / 1.00 mm / 1.25 mm / 1.46 mm / 1.579 mm / 1.875 mm / 2.00 mm / 2.50 mm

Module Resolution
• 248 × 279 / 240 × 270 / 192 × 216 / 164 × 184 / 152 × 171 / 128 × 144 / 120 × 135 / 96 × 108 Pixels

Module Dimensions
• 240 × 270 × 13 mm

Module Weight
• 0.38 kg

Module Composition
• 4 × 1 Modules

Cabinet Resolution
• 992 × 279 / 960 × 270 / 768 × 216 / 656 × 184 / 608 × 171 / 512 × 144 / 480 × 135 / 384 × 108 Pixels

Cabinet Dimensions
• 960 × 270 × 13 mm

Cabinet Surface Area
• 0.2592 m²

Cabinet Weight
• 20 kg/m²

Pixel Density
• Up to 1,067,208 Pixels/m² (Model Dependent)

Surface Flatness
• ≤0.3 mm

Brightness Calibration
• Yes

Color Calibration
• Yes

Brightness
• 800 Nits (After Calibration)

Horizontal Viewing Angle
• 160°

Vertical Viewing Angle
• 140°

Brightness Uniformity
• ≥97%

Contrast Ratio
• 7000:1

Maximum Power Consumption
• 550 W/m²

Average Power Consumption
• 200–230 W/m² (Model Dependent)

Power Supply
• AC 200–240V, 50Hz

Frame Rate
• 50 / 60 Hz

Refresh Rate
• ≥3840 Hz

LED Lifetime
• Up to 100,000 Hours

Operating Temperature
• -20°C to +40°C

Storage Temperature
• -30°C to +60°C

Operating Humidity
• 10–80% RH (Non-Condensing)

Storage Humidity
• 10–85% RH (Non-Condensing)
