Pixel Configuration
• SMD 3-in-1 LED

Pixel Pitch
• 1.25 mm

Module Resolution
• 240 × 135 Pixels

Module Dimensions
• 300 × 168.75 mm

Module Weight
• 0.29 kg

Modules per Cabinet
• 4 Modules

Cabinet Resolution
• 480 × 270 Pixels

Cabinet Dimensions (W × H × D)
• 600 × 337.5 × 29.5 mm

Cabinet Surface Area
• 0.203 m²

Cabinet Weight
• 5.2 kg

Weight per Square Meter
• 25.7 kg/m²

Pixel Density
• 640,000 Pixels/m²

Cabinet Flatness
• ±0.1 mm

Cabinet Material
• Die-Cast Aluminum

Service Access
• Front Maintenance

Brightness
• 800 Nits (After Calibration)

Color Temperature
• Adjustable from 3000K to 10000K

Viewing Angle
• Horizontal: 160°
• Vertical: 160°

Brightness Uniformity
• 98.2%

Color Uniformity
• ±0.003 Cx, Cy

Contrast Ratio
• 7000:1

Processing Depth
• 14-bit

Power Consumption
• Maximum: 110W per Cabinet (543W/m²)
• Average: 35W per Cabinet

Heat Dissipation
• Maximum: 376 BTU/h per Cabinet
• Average: 125 BTU/h per Cabinet
• Maximum: 1857 BTU/h per m²

Power Supply
• AC 100–240V

Frame Rate
• 50 / 60 Hz

Refresh Rate
• 3840 Hz

LED Lifetime
• Up to 100,000 Hours (50% Brightness)

Operating Temperature
• -10°C to +45°C

Operating Humidity
• 10%–90% RH

IP Rating
• IP30 (Indoor)

Application
• Indoor LED Display System
