Decoding Format

• Ultra 265, H.265, H.264

Decoding Capability

• 4 x 12MP@20, 4 x 4K@30, 16 x 1080P@30, 36 x 720P@30, 64 x D1

Decoding Capability Description

• The resolution of each channel cannot exceed 4096 pixels in length or width

Audio Compression

• G.711A, G.711U

Incoming Bandwidth

• NVR516-64: 384 Mbps

• NVR516-128: 512 Mbps

Outgoing Bandwidth

• 384 Mbps

Remote Users

• 128

Protocols

• TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS, RTSP, 802.1x, IPv6, IPv4

Browser (Plugin)

• IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

IP Video Input

• NVR516-64: 64-ch

• NVR516-128: 128-ch

BNC Audio Input

• 1-ch

HDMI Output

• 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz (HDMI audio output is not supported)

VGA Output

• 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

BNC Audio Output

• 1-ch

Liveview Display

• VGA: 1/4/6/8/9/16/25/36

• HDMI1/HDMI2: 1/4/6/8/9/16/25/36/64

Corridor Mode Screen

• 3/4/5/7/9/10/12/16/32

Two-way Audio

• 1-ch, BNC (Using the audio input and output)

Snapshot

• FTP/Schedule/Event Snapshot, Full-ch snapshot (max. 4000 × 3000 video resolution, with snapshot resolution same as the video resolution)

Recording Resolution

• 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF

Synchronous Playback in Local

• 16-ch

VCA Detection by IPC

• Face Detection, Vehicle Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD), Temperature Detection (Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), People Counting (People Flow Counting, Crowd Density Monitoring), Video Metadata, Traffic Monitoring

VCA Search

• Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report

Smart by IPC

• All channels (up to 32 images/s in total) Face Detection, Vehicle Detection, Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring

General Alarm

• Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection

Alert Alarm

• IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal, High CPU Temperature, High Motherboard Temperature, Array Damaged, Array Degraded

GUI Language

• 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

SATA

• 16 SATA Interfaces

Capacity

• Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature)

Disk Array Type

• RAID 0, 1, 5, 6, 10, 50, 60

Hot Swap

• Support

Network Interface

• 4 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface, 2 1000 M SFP Ethernet Interface

USB

• Rear panel: 4 × USB3.0

RS485

• 1

RS232

• 1

Alarm In

• 24-ch

Alarm Out

• 8-ch

eSATA

• 1

miniSAS

• 2

Power Output

• 12 V

Power Supply

• AC 100 to 240 V

Power Switch

• Support

Redundant Power Supply

• Support

Working Temperature

• -10 ℃ to 55 ℃ (14 ℉ to 131 ℉)

Working Humidity

• ≤ 90% RH (non-condensing)

Power Consumption (without HDD)

• ≤ 50W

Weight (without HDD)

• ≤ 10Kg (22.05lb)

Dimensions

• 482mm × 477mm × 131mm (19.0" × 18.8" × 5.2")

Certification

• CE; FCC; UL; RoHS; WEEE, CEEN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035, FCCPart15 Subpart B
