Decoding Format

• Ultra 265, H.265, H.264

Decoding Capability (NVR304-16B-IQ)

• Smart Off: 2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 10 x 1080P@30, 16 x 720P@30

• Smart On: 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30

Decoding Capability (NVR304-32B-IQ)

• Smart Off: 2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 10 x 1080P@30, 20 x 720P@30, 32 x D1

• Smart On: 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30, 32 x D1

Decoding Capability Description

• The resolution of each channel cannot exceed 8192 pixels in length and 4096 pixels in width

Audio Compression

• G.711A, G.711U

Incoming Bandwidth

• 160 Mbps

Outgoing Bandwidth

• 128 Mbps

Remote Users

• 128

Protocols

• TCP/IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4, 802.1x, UPnP

Browser (Plugin)

• IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

IP Video Input

• NVR304-16B-IQ: 16-ch

• NVR304-32B-IQ: 32-ch

RCA Audio Input

• 1-ch

Peripheral Input

• IP Speaker: 16-ch

• POS: All channels

HDMI Output

• 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

• 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

RCA Audio Output

• 1-ch

Liveview Display

• NVR304-16B-IQ: 1/4/6/8/9/16

• NVR304-32B-IQ: 1/4/6/8/9/16/25/32

Corridor Mode Screen

• NVR304-16B-IQ: 3/4/5/7/9/10/12/16

• NVR304-32B-IQ: 3/4/5/7/9/10/12/16/32

Two-way Audio

• 1-ch, RCA (Using the audio input and output)

Snapshot

• FTP/Schedule/Event Snapshot, 4-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution)

Recording Resolution

• 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF

Synchronous Playback in Local

• 16-ch

Smart Function (Smart by IPC)

• All channels (up to 8 images/s in total) Face Detection, Vehicle Detection (LPR), SIP, UMD, Traffic Monitoring

Smart Function (Smart by NVR)

• Face Detection, Smart Intrusion Prevention (SIP), Ultra Motion Detection (UMD)

Smart by NVR Analyzer Mode

• Single Mode (), Single Mode (SIP), Single Mode (UMD), Single Mode (AcuSearch/AcuTrack). Modes cannot active simultaneously, only one mode can active at a time.

VCA Search

• AcuSearch, AcuTrack, Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map

AcuSearch / AcuTrack Performance

• All channels with UNV SIP/UMD Camera

Face Detection by NVR

• Up to 8-ch with UNV Face Detection Camera, Up to 1-ch with normal camera (UNV and Third-party brand, 1-ch 2MP)

Plate Comparison (Vehicle Number Library)

• Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total

SIP by NVR with normal cameras

• Up to 2-ch with normal camera (UNV and Third-party brand, 2-ch 2MP, 1-ch 4MP)

UMD by NVR with normal cameras

• Up to 4-ch with normal camera (UNV and Third-party brand, 4-ch 2MP, 2-ch 4MP, 1-ch 4K)

General Alarm

• Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection

Alert Alarm

• IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

• 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

SATA

• 4 SATA Interfaces

Capacity

• Up to 24 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size, The environment temperature for use should not exceed 40°C)

Network Interface

• 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface

USB

• Front panel: 1 × USB2.0, Rear panel: 1 × USB2.0, 1 × USB3.0

RS485 / RS232

• N/A

Alarm In / Alarm Out

• N/A

Power Supply

• DC 12 V/5 A

Working Temperature

• -10 ℃ ~ + 55 ℃ (+14 ℉ ~ +131 ℉)

Working Humidity

• ≤ 90% RH (non-condensing)

Power Consumption (without HDD)

• ≤ 12W

Weight (without HDD)

• ≤ 3.4Kg (7.5lb)

Dimensions

• 440mm × 350mm × 48mm (17.3" × 13.8" × 1.9"){C}{C}

Certification{C}{C}

• CE; FC{C}C; UL; RoHS; WEEE, CEEN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035, FCCPart15 Subpart B
