Decoding Format

• Ultra 265, H.265, H.264

Decoding Capability (NVR508-16B)

• Ultra 265/H.265: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30

• H.264: 2 x 16MP(4800*2688)@30, 2 x 12MP@30, 2 x 4K@30, 4 x 5MP@30, 6 x 4MP@30, 8 x 3MP@30, 14 x 1080P@30, 16 x 960P@30

Decoding Capability (NVR508-32B)

• Ultra 265/H.265: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30, 32 x 960P@25

• H.264: 2 x 16MP(4800*2688)@30, 2 x 12MP@30, 2 x 4K@30, 4 x 5MP@30, 6 x 4MP@30, 8 x 3MP@30, 14 x 1080P@30, 28 x 960P@25, 30 x 720P@30, 32 x D1

Decoding Capability (NVR508-64B)

• Ultra 265/H.265: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30, 32 x 960P@25, 36 x 720P@30, 64 x D1

• H.264: 2 x 16MP(4800*2688)@30, 2 x 12MP@30, 2 x 4K@30, 4 x 5MP@30, 6 x 4MP@30, 8 x 3MP@30, 14 x 1080P@30, 28 x 960P@25, 30 x 720P@30, 64 x D1

Decoding Capability Description

• The resolution of each channel cannot exceed 8192 pixels in length and 4096 pixels in width, For VGA/HDMI independent output, the VGA live video is output by default. To output the highest resolution video from the HDMI port, please clear the VGA video on the preview page.

Audio Compression

• G.711A, G.711U

Incoming Bandwidth

• 320 Mbps

Outgoing Bandwidth

• 160 Mbps

Remote Users

• 128

Protocols

• TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, 802.1x, IPv6, IPv4

Browser (Plugin)

• IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

IP Video Input

• NVR508-16B: 16-ch / NVR508-32B: 32-ch / NVR508-64B: 64-ch

RCA Audio Input

• 1-ch

HDMI Output

• 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

• 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

RCA Audio Output

• 1-ch

Liveview Display

• NVR508-16B: 1/4/6/8/9/16

• NVR508-32B: 1/4/6/8/9/16/25/36

• NVR508-64B: Simultaneous Output (VGA/HDMI: 1/4/6/8/9/16/25/36/64), Independent Output (VGA/HDMI: 1/4/6/8/9/16/25/32)

Corridor Mode Screen

• NVR508-16B: 3/4/5/7/9/10/12/16

• NVR508-32B / NVR508-64B: 3/4/5/7/9/10/12/16/32

Two-way Audio

• 1-ch, RCA (Using the audio input and output)

Snapshot

• FTP/Schedule/Event Snapshot, 4-ch snapshot (max. 8 MP (3840 × 2160) video resolution, with 1080P snapshot resolution)

Recording Resolution

• 16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF

Synchronous Playback in Local

• 16-ch

Smart Function (Smart by IPC)

• All channels (up to 8 images/s in total) Face Detection, Vehicle Detection (LPR), Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring

VCA Search

• Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map

General Alarm

• Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection

Alert Alarm

• IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

• 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

SATA

• 8 SATA Interfaces

Capacity

• Up to 24 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size, The environment temperature for use should not exceed 40°C)

Disk Group

• Support

Redundant Storage

• Support

Disk Array Type

• RAID 1, 5

Network Interface

• 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface

USB

• Front panel: 2 × USB2.0, Rear panel: 1 × USB3.0

RS485

• 1RS485

RS232

• N/A

Alarm In

• 16-ch

Alarm Out

• 4-ch

Power Supply

• AC 100 to 240 V

Power Switch

• Support

Working Temperature

• -10 ℃ to 55 ℃ (14 ℉ to 131 ℉)

Working Humidity

• ≤ 90% RH (non-condensing)

Power Consumption (without HDD)

• ≤ 25W

Weight (without HDD)

• ≤ 5.5Kg (12.13lb)

Dimensions

• NVR508-16B: 442mm × 431.4mm × 88.6mm (17.4" × 17.0" × 3.5")

• NVR508-32B / NVR508-64B: 442mm × 426mm × 89mm (17.4" × 16.8" × 3.5")

Certification

• CE; FCC; UL; RoHS; WEEE, CEEN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035, FCCPart15 Subpart B
