Decoding Format

• Ultra 265, H.265, H.264

Decoding Capability

• NVR301-04S3: 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25

• NVR301-08S3: 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30

• NVR301-16S3: 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30, 16 x D1@25

• Note: The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width

Audio Compression

• G.711A, G.711U

Incoming Bandwidth

• 64 Mbps

Outgoing Bandwidth

• 48 Mbps

Remote Users

• 128

Protocols

• TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4

Browser (Plugin)

• IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

IP Video Input

• NVR301-04S3: 4-ch

• NVR301-08S3: 8-ch

• NVR301-16S3: 16-ch

HDMI Output

• 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

• 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

3.5mm Audio Output

• 1-ch

Liveview Display

• NVR301-04S3: 1/4

• NVR301-08S3: 1/4/6/8/9

• NVR301-16S3: 1/4/6/8/9/16

Corridor Mode Screen

• NVR301-04S3: 3/4

• NVR301-08S3: 3/4/5/7/9

• NVR301-16S3: 3/4/5/7/9/10/12/16

Snapshot

• FTP/Schedule/Event Snapshot 1-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution)

Recording Resolution

• 8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF

Synchronous Playback in Local

• NVR301-04S3: 4-ch

• NVR301-08S3: 8-ch

• NVR301-16S3: 16-ch

Smart Function by IPC

• Total 4-ch (Face Detection, SIP, UMD)

VCA Search

• Behavior Search

Capacity of Smart Snapshots

• 2 millions records for face snapshot

General Alarm

• Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection

Alert Alarm

• IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

• 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian

Hard Disk SATA

• 1 SATA Interface (Up to 10 TB for each HDD - The maximum HDD capacity varies with environment temperature and hard disk size)

Network Interface

• 1 RJ45 10 M/100 M self-adaptive Ethernet Interface

USB

• Rear panel: 2 × USB2.0

Other Interfaces (RS485 / RS232 / Alarm In & Out)

• Not Available (N/A)

Power Supply

• DC 12 V/2 A

Power Consumption (without HDD)

• ≤ 5W

Working Temperature

• -10 ℃ to 55 ℃ (14 ℉ to 131 ℉)

Working Humidity

• ≤ 90% RH (non-condensing)

Weight (without HDD)

• ≤ 0.98Kg (2.16lb)

Dimensions

• 260mm × 240mm × 46mm (10.2"×9.4"×1.8")

Certification

• CE; FCC; UL; RoHS; WEEE; CE EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035; FCC Part15 Subpart B
