Max Resolution / Sensor

• 2 MP / 1/2.7" CMOS

Min. Illumination

• Color: 0.003 Lux (F1.2, AGC ON), 0 Lux with IR

Day/Night / Shutter

• IR-cut filter with auto switch (ICR) / Auto/Manual, 1 to 1/100000 s

WDR / S/N

• 120 dB / ＞52dB

Lens Specs

• Focal Length: 2.7 to 13.5 mm (5X Optical Zoom)

• Iris: F1.2

• Field of View: H: 104.9° to 30.6°, V: 55.41° to 17.7°, D: 136.37° to 36.1°

DORI Distance (2.7 to 13.5 mm)

• Detect: 70.9 m to 247.5 m (232.5 ft. to 812.0 ft)

• Observe: 28.4 m to 99.0 m (93.2 ft. to 324.8 ft)

• Recognize: 14.2 m to 49.5 m (46.5 ft. to 162.4 ft)

• Identify: 7.1 m to 24.8 m (23.3 ft. to 81.4 ft)

PTZ Settings

• Pan / Tilt Range: Pan: 350°, Tilt: 0° to 90°

• Pan / Tilt Speed: Pan: 0.1°/s to 60°/s, Tilt: 0.1°/s to 50°/s

• Presets / Patrol: 1024 Presets / 16 patrols (up to 64 presets per patrol)

• Patrol Stay Time: 1800 s to 3600 s

• Home Position / Preset Image Freeze: Support / N/A

Video Compression & Stream

• Ultra 265, H.265, H.264, MJPEG

• Main Stream: 1080P (1920 × 1080), max. 30 fps

• Sub Stream: 720P (1280 × 720), max. 30 fps

• Third Stream: D1 (720 × 576), max. 30 fps

• Video Bit Rate / U-code: 128 Kbps to 16 Mbps / Support

• OSD / Privacy Mask: Up to 8 OSDs / 24 areas (max 4 per scene)

• ROI / Video Stream: Support / Triple streams

Intelligent & Analytics

• Smart Intrusion Prevention: Cross line, intrusion, enter area, leave area detection (with human/vehicle classification)

• Exception Detection: Object removed, Object Left Behind, Scene change, Defocus detection

• Basic Detection: Motion detection, Tampering alarm, Audio detection

Image Settings

• White Balance: Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2

• Digital Noise Reduction: 2D/3D DNR

• Flip / Smart IR: Normal, Flip vertical, Flip horizontal, 180° / Support

• HLC / BLC / Defog: Support / Support / Digital defog

• Heatwave Reduction: N/A

Illuminator

• Supplemental Light / Wavelength: IR / 850 nm

• Illumination Distance (IR): 30 m (98.4 ft)

• Light On/Off Control: Auto/Manual

Audio

• Audio Compression / Bitrate: G.711U, G.711A / 128 Kbps

• Two-way Audio / Suppression: Support / Support

• Sampling Rate: 16KHZ

Storage & Network

• Edge Storage / Network Storage: MicroSD (up to 512 GB) / ANR, NAS (NFS)

• Protocols: SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS

• Compatible Integration: ONVIF (Profile S, Profile G, Profile T), API, SDK

• User/Host: Up to 32 users, 3 user levels (administrator, common user, operator)

• Security: TLS 1.3, TLS 1.2, Password Protection, Strong Password, HTTPS Encryption, Export Logs, Authentication for RTSP/HTTP/ONVIF

• Client / Browser: EZStation, UNV-Link, UNV-Link Pro / IE 10+, Chrome 45+, Firefox 52+, Edge 79+

Interface

• Alarm I/O / Serial Port: 1/1 / 1 × RS485

• Built-in Mic & Speaker: Support / Support

• Network: 1 × RJ45 10 M/100 M Base-TX Ethernet

• Audio I/O / Video Output / Reset Button: N/A / N/A / Support

Certification & Environment

• EMC: CE-EMC, FCC

• Safety: CE LVD, CB, UL

• Environment / Surge Protection: CE-ROHS / 4 KV

General

• Power / Power Interface: DC 12 V (±25%), PoE (IEEE 802.3at) / Ø5.5 mm coaxial plug

• Power Consumption: Max. 15 W

• Dimensions / Weight: Ø129 mm × 143.6 mm / 0.76 kg (1.67 lb)

• Material: Plastic

• Working Environment: -10 ℃ to 50 ℃, Humidity: ≤ 95% RH

• Storage Environment: -40 ℃ to 70 ℃, Humidity: ≤ 95% RH

• Configurable P/N / Language: Support / 22 Languages (including English)
