Max Resolution

• 2 MP

Sensor

• 1/2.9" CMOS

Min. Illumination

• Color: 0.01 Lux (F2.0, AGC ON), 0 Lux with IR on

Day/Night

• IR-cut filter with auto switch (ICR)

Shutter

• Auto/Manual, 1 ~ 1/100000s

Adjustment Angle

• Pan: 0° to 355°, Tilt: 0° to 75°

S/N / WDR

• S/N: >52 dB, WDR: DWDR

Lens

• Focal Length: 2.8 mm

• Iris Type: Fixed

• Iris: F2.0

• Field of View: H: 101.1°, V: 56.5°, D: 117°

DORI Distance (Lens: 2.8 mm)

• Detect: 45.0 m (147.6 ft.)

• Observe: 18.0 m (59.1 ft.)

• Recognize: 9.0 m (29.5 ft.)

• Identify: 4.5 m (14.8 ft.)

Illuminator

• Supplemental Light: IR{C}

• Illumination Distance (IR): 30 m (98.4 ft.){C}

• Wavelength: 850 nm{C}

• IR On/Off Control: Auto/Manual{C}

Video Compression{C}

• Ultra 265, H.265, H.264{C}

• H.264 Code Profile: Baseline profile, Main profile, High profile{C}

Frame Rate{C}

• Main Stream: 1080P (1920 × 1080), max. 30 fps; 720P (1280 × 720), max. 30 fps

• Sub Stream: D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps

Video Bit Rate / U-code

• Bit Rate: 128 Kbps to 6144 Kbps

• U-code: Support (main stream)

Image Settings

• OSD: Up to 4 OSDs

• Privacy Mask: Up to 4 areas

• ROI: Support

• Video Stream: Dual streams

• White Balance: Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2

• Digital Noise Reduction: 2D/3D DNR

• Smart IR: Support

• Flip: Normal, Flip vertical, Flip horizontal, 180°

• Dewarping: N/A

• HLC / BLC: Support

• Defog: Digital defog

Events & Functions

• Basic Detection: Motion detection

• General Function: Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication{C}{C}

Storage{C}{C}

• Edge Storage: MicroSD, up to 128 GB{C}{C}{C}

Network{C}{C}{C}

• Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP{C}, HTTPS, S{C}SL/TLS{C}

• Compatible Integration: ONVIF (Profile S, Profile G, Profile T), API, SDK{C}{C}

• User/Host: Up to 32 users, 2 user levels: {C}administrator and common user{C}

• Security: Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for {C}RTSP, Digest Authentication for HTTP, WSSE and Digest Authentication for ONVIF{C}

• Client: UNV-Link, UNV-Link Pro, EZStation{C}

• Web Browser: Plug-{C}in required: IE 10+, Chrome 45+, Firefox 52+, Edge 79+. Plug-in free: Chrome 57+, Firefox 58+, Edge 16+

Interface

• Audio / Alarm I/O: N/A

• Serial Port / Built-in Mic & Speaker / WIFI: N/A

• Network: 1 × RJ45 10 M/100 M Base-TX Ethernet

• Video Output: N/A

Certification

• EMC: CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B)

• Safety: CE LVD (EN 62368-1), CB (IEC 62368-1), UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)

• Environment: CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)

• Protection: IP67 (IEC 60529), IK10 (IEC 62262)

General

• Power: DC 12 V±25%, PoE (IEEE 802.3af)

• Power Consumption: Max. 5.0 W

• Power Interface: Ø5.5 mm coaxial power plug

• Dimensions: Ø109 mm × 81 mm (Ø4.3" × 3.2") (Ø × H)

• Weight: 0.36 kg (0.79 lb.)

• Material: Metal + Plastic

• Working / Storage Environment: Temperature: -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)

• Surge Protection: 4 KV

• Reset Button: N/A

• Web Client Language: English
