System & General

• OS: Embedded Linux

• Dimensions: 437 × 483 × 143 mm

• Power Supply: ATX-275W

• Power Consumption: ≤ 50W (without HDD)

• Operating Environment: -10°C ~ 50°C | Humidity: 10% ~ 90%

• Certifications: CE, FCC, EU RoHS, WEEE, REACH

Model Comparison (IP Video Channels & Bandwidth)

• TD-3364H16-A3H:

  • IP Video Input: 64 Channels

  • Network Bandwidth: Incoming: 640 Mbps | Outgoing: 640 Mbps

  • Audio Network Input: 64 Channels

  • Face Detection (AI by IPC): 64 Channels

  • Human/Vehicle Classification (AI by IPC): 64 Channels

• TD-33128H16-A3H:

  • IP Video Input: 128 Channels

  • Network Bandwidth: Incoming: 768 Mbps | Outgoing: 768 Mbps

  • Audio Network Input: 128 Channels

  • Face Detection (AI by IPC): 128 Channels

  • Human/Vehicle Classification (AI by IPC): 128 Channels

Video & Compression

• Supported Resolutions: 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1280×1024, 960P, 720P, 960H, D1, CIF

• Video Compression: H.264, H.265, H.265+, H.265S

• Audio Compression: G.711 (U/A)

Video Output & Display

• HDMI1 Output: 7680×4320 @ 60/30Hz (8K), 3840×2160 @ 60/30Hz (4K), 1920×1080, 1280×1024, 1024×768 (Note: When HDMI1 outputs 8K, HDMI2 is disabled)

• HDMI2 & HDMI3 Outputs: Up to 3840×2160 @ 60/30Hz (4K), 1920×1080, 1280×1024, 1024×768

• HDMI4 Output: Up to 1920×1080, 1280×1024, 1024×768

• VGA Output: 1× VGA (1920×1080, 1280×1024, 1024×768) - Mirrors HDMI1

• Multi-Screen Display:

  • Main Output: 1, 4, 6, 8, 9, 13, 16, 25, 32, 36, 64

  • AUX Output 1: 1, 4, 6, 8, 9, 13, 16, 25, 32, 36

  • AUX Output 2: 1, 4, 6, 8, 9, 13, 16

  • AUX Output 3: 1, 4, 6, 8, 9, 13, 16

  • Max Multi-screen Layout: 132 Channels (64 + 36 + 16 + 16)

Playback & Decoding

• Simultaneous Playback: 16 Channels

• Frame Rate: NTSC: 30fps | PAL: 25fps

• Live View Decoding: 1CH 16MP @ 30fps / 4CH 12MP (Main output only)

• Playback Decoding: 1CH 16MP @ 30fps / 4CH 8MP (Main output only)

• Search Options: Time slice, Time, Event, Tag, Smart search

AI & Analytics

• Face Detection (AI by Device): 4 Channels

• Face Match Performance: 16 Channels (36 pictures/second comparison)

• Face Database: 32 libraries (Up to 10,000 face pictures total)

• Human/Vehicle Classification (AI by Device): 8 Channels

• Other AI Features: Human/Vehicle Attribute Analysis, License Plate Recognition (AI by IPC), Fisheye Access, Track display on map, Statistical graphs

Storage & Interfaces

• HDD Interfaces: 16× SATA ports (Up to 10 TB per HDD; 160 TB Max)

• RAID Support: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10

• External Storage: 2× eSATA ports

• Network Interfaces: 2× RJ45 10/100/1000Mbps Ethernet ports

• USB Ports: 1× USB 3.0, 3× USB 2.0 (2 Front, 1 Rear)

• Audio I/O: 1× RCA Input, 1× RCA Output, HDMI Audio Output

• Alarm I/O: 24 Channels Input / 8 Channels Output

• Serial Interfaces: 1× RS485 (Full-duplex), 1× RS232

• Max Remote Connections: 128 users (iOS & Android supported)
